Description
SPECIFICATIONS:
- Laser: 905 nm, Class I
- Beam Divergence: 3 mrad
- Returns: Single (Strongest, first)
- Channel: 16
- FOV: (Horizontal): 360°, (Vertical): -15°~+15°
- Scanning Frequency: 5/10 Hz
- Angular Resolution (Vertical): 2 +/- 0.1°
- Angular Resolution (Horizontal) 0.18° ±10% @10Hz
- Measurement Range: 0.5 ~ 100 m@80% reflectivity
- Distance Resolution: 2 mm
- Accuracy: +/- 3 cm
- Data Point Rate: 310K pts/sec.
- Ethernet Connection: 100M Ethernet
- UDP Packets: Distance, Reflectivity, Rotation Angle, Sync Time Stamps
- Reflectivity Data: 5-100%
- High Reflector Recognition: YES
- Connection: 2 x 8 pin aviation plugs
- Dimensions: 96mm(D) x 110mm (H)
- Operation Voltage: Power1: 8-14V, Power2: 14-17V, Power3: 14-17V
- Power Consumption: < 11W
- Weight: <1500g
- Degree of Protection: IP66
- Operation Temperature: -10°C ~ 50°C
- Storage Temperature: -20°C ~ 60°C
- Ambient Light Limit: 80000 LUX
- Air Humidity: <95%RH
- Mounting: Bottom
- EMC: IEC 61000-6-2:2016-08 /IEC 61000-6-3:2006-07
- Vibration Resistance: IEC 60068-2-6:2007
- Shock Resistance: IEC 60068-2-27:2008
