Description
SPECIFICATIONS:
- Laser: Class 1 905nm ± 20nm
- Channels: 32 lines
- FOV(H): 360
- FOV(V): ± 15°
- Vertical Resolution: 1°
- Beam Divergence: ＜6mrad*3mrad
- Spot Size: ＜60mm*34mm@10M(1/e2)
- Scanning Frequency: 5/10/20Hz
- Number of Echoes: Double echo
- Distance Resolution: 2mm
- Measurement Range:
- 0.2～50m@2% reflectivity
- 0.2～150m@10% reflectivity
- 0.2～200m@30% reflectivity
- Absolute Accuracy: ±2cm(＜0.5m,3cm;＞0.5m,2cm)
- Repeat Accuracy: 2cm
- Signal Strength: 0-255
- Data Transmission: UDP/IP Ethernet(100Mbps)
- Data Contents: Distances/ Calibrated Reflectivities/ Rotation Angles/ Synchronized Time Stamps
- Data Rate: 576000 single echo, 1152000 double echo
- Connection: 12pin aviation plug with adapter box
- Mechanical Dimensions: 84mm x 102mm
- Power: ≤ 12W
- Weight: < 1000g
- Degree of Protection: IP67
- Operating Temperature: -20C ~ 60C
- Storage Temperature: -40C ~ 85C
- Air Humidity: 95%
- Ambient Light Limit: 120K Lux
- Voltage: 9~30V
- Basic Software: Olamview ROS Driver
- GPS: Supported
- PPS: Supported
- EMC: IEC61000-6-2 IEC61000-6-3
- Vibration Resistance: IEC60068-2-6
- Shock Resistance: IEC60068-2-27
- Hazardous Substance: Reach /RohS
- National Certification: CE/UKCA
